Navigator Scorpio
20,550 cbm LPG CARRIER
Main Engine
MAN B&W S46MC-C
NOM RATING: 7,860 kW / 129 rpm
MAN B&W S46MC-C
NOM RATING: 7,860 kW / 129 rpm
Cargo Tanks
Bi-lobe × 4
Independent Type C (−48°C; 5.3 Bar)
Bi-lobe × 4
Independent Type C (−48°C; 5.3 Bar)
Deadweight
24,172 mt
24,172 mt
Deck Tank
155 CBM (−48°C; 18.2 Bar) × 2
155 CBM (−48°C; 18.2 Bar) × 2
Service Speed
16 knots
16 knots
HFO Capacity
1,966 cbm
1,966 cbm
FOC
~29 mt/day
~29 mt/day
MGO Capacity
231 cbm
231 cbm
Cruising Range
23,500 Nm
23,500 Nm
FW Capacity
385 cbm
385 cbm
Reliquefaction Plant
Direct Type × 2 sets
Sulzer Compressors × 3
Direct Type × 2 sets
Sulzer Compressors × 3
Cargo System
| Main Cargo Pump | Elec. Motor Driven × 8 |
|---|---|
| Svanehoy | Deepwell Type |
Power Supply
| Hyundai Himsen 5H21/32 × 3 7 | 780 kW (ea) |
|---|---|
| TOTAL: 3 generators | 2,340 kW |
Water Ballast
| Storage Capacity | 9,204 cbm |
|---|---|
| Segregated Ballast | Yes |
| Capacity per unit (2) | 370 cbm/hr |
Main Dimensions
| LOA | 159.97 m |
|---|---|
| Beam | 25.60 m |
| Depth | 16.40 m |
| Draft (Tropical) | 11.15 m |
| Draft (Ballast) | 7.50 m |
Class
Lloyds Register
Lloyds Register
Cargoes
- Ammonia
- Butadiene
- Butane
- Propane
- Propylene (pgm)
- Propylene Ox.
- V.C.M
